TC1796
Peripheral Units (Vol. 2 of 2)
General Purpose Timer Array (GPTA)
User’s Manual 24-127 V2.0, 2007-07
GPTA, V2.0
Variables
Input, Local, Output variables of the cell (I, L, O)
Global variables
Name k = [0 to 3] for DCM Short
Name
Used
(ILO)
Comment
DCMk.Signal_Input.Transition
DCMk.Signal_Input.Level
*SITk
*SILk
I Input of the cell
DCMk.Signal_Output *SOk O Output of the cell
DCMk.Service_Request_Rising *RTQk O Service request on rising edge
DCMk.Service_Request_Falling *FTQk O Service request on falling edge
DCMk.Service_Request_Compare *CTQk O Service request on compare
event
Name k = [0 to 3] for DCM Short
Name
(*)DCM
Size
(bits)
Function
DCMk.Capture_On_Rising_Edge *RCAk 1 Capture into Capture_Value on
rising edge
DCMk.Capcom_Opposite *OCAk 1 Capture into Capcom_Value on
opposite edge defined by RCAk
DCMk.Clear_On_Rising_Edge *RZEk 1 Clear Timer on rising edge
DCMk.Clear_On_Falling_Edge *FZEk 1 Clear Timer on falling edge
DCMk.Clock_On_Rising_Edge *RCKk 1 Generate a single clock pulse on
rising edge
DCMk.Clock_On_Falling_Edge *FCKk 1 Generate a single clock pulse on
falling edge
DCMk.Clock_Request *QCKk 1 Generate a single clock pulse
immediately
DCMk.Request_Enable_Rising *RREk 1 Enable request on rising edge
DCMk.Request_Enable_Falling *FREk 1 Enable request on falling edge
DCMk.Request_Enable_Compare *CREk 1 Request enable on compare
DCMk.Timer *TIMk 24 Timer value
