TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-167 V2.0, 2007-07

GPTA, V2.0

GPTA0_PLLSTP

GPTA0 Phase Locked Loop Step Register

(0CC

) Reset Value: 0000 0000

GPTA1_PLLSTP

GPTA1 Phase Locked Loop Step Register

(0CC

) Reset Value: 0000 0000

31 16 15 0

0STP

rrw

Field Bits Type Description

STP [15:0] rw Step Value

Number of output pulses to be generated within one

input signal period (2-complement data format).

0 [31:16] r Reserved

Read as 0; should be written with 0.

GPTA0_PLLCNT

GPTA0 Phase Locked Loop Counter Register

(0C8

) Reset Value: 0000 0000

GPTA1_PLLCNT

GPTA1 Phase Locked Loop Counter Register

(0C8

) Reset Value: 0000 0000

31 16 15 0

0CNT

rrwh

Field Bits Type Description

CNT [15:0] rwh Pulse Counter

Counter for the number of remaining output pulses to

be generated.

0 [31:16] r Reserved

Read as 0; should be written with 0.
