GPTA0_PLLREV
GPTA0 Phase Locked Loop Reload Register
(0D0
H
) Reset Value: 0000 0000
H
GPTA1_PLLREV
GPTA1 Phase Locked Loop Reload Register
(0D0
H
) Reset Value: 0000 0000
H
31 24 23 0
0REV
rrw
Field Bits Type Description
REV [23:0] rw Reload Value
Reload value calculated by a subtraction of the
number of output pulses to be generated within one
input signal period from the input signal’s period
length (measured in number of GPTA module clocks).
0 [31:24] r Reserved
Read as 0; should be written with 0.
GPTA0_PLLDTR
GPTA0 Phase Locked Loop Delta Register
(0D4
H
) Reset Value: 0000 0000
H
GPTA1_PLLDTR
GPTA1 Phase Locked Loop Delta Register
(0D4
H
) Reset Value: 0000 0000
H
31 25 24 0
0DTR
rrwh
Field Bits Type Description
DTR [24:0] rwh Delta Register Value
Internal register used to store intermediate results for
output pulse generation.
Do not write to this register while PLL is running!
