TC1796
Peripheral Units (Vol. 2 of 2)
General Purpose Timer Array (GPTA)
User’s Manual 24-182 V2.0, 2007-07
GPTA, V2.0
CEN 10 rh Cell Enable
0
B
LTCk is currently disabled for local events.
1
B
LTCk is currently enabled for local events.
OCM [13:11] rw Output Control Mode Select
X00
B
Current state of LTCkOUT output line is hold.
X01
B
Current state of LTCkOUT output line is toggled.
X10
B
LTCkOUT output line is forced to 0.
X11
B
LTCkOUT output line is forced to 1.
0XX
B
LTCkOUT output line state is set by an internal
LTCk event only.
1XX
B
LTCkOUT output line state is affected by an
internal LTCk event and/or by an operation
occurred in an adjacent LTCk cell (reported by
M1I/M0I interface lines).
OIA 14 rw Output Immediate Action
0
B
No immediate action required.
1
B
Action defined by bit field OCM must be
performed immediately.
OIA is always read as 0.
OUT 15 rh Output State
0
B
LTCkOUT output line is 0.
1
B
LTCkOUT output line is 1.
0 [31:16] r Reserved
Read as 0; should be written with 0.
Field Bits Type Description
