Node Redirection Register
The Service Request Node Redirection Register allows that GTC service requests of
GTCs with an odd index number k can be individually redirected via register SRNR to a
service request group that is assigned mainly to four LTCs. More details are provided on
Page 24-113.
GPTA0_SRNR
GPTA0 Service Request Node Redirection Register
(030
H
) Reset Value: 0000 0000
H
GPTA1_SRNR
GPTA1 Service Request Node Redirection Register
(030
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
r
1514131211109876543210
GTC
31R
GTC
29R
GTC
27R
GTC
25R
GTC
23R
GTC
21R
GTC
19R
GTC
17R
GTC
15R
GTC
13R
GTC
11R
GTC
09R
GTC
07R
GTC
05R
GTC
03R
GTC
01R
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Field Bits Type Description
GTC01R,
GTC03R,
GTC05R,
GTC07R,
GTC09R,
GTC11R,
GTC13R,
GTC15R,
GTC17R,
GTC19R,
GTC21R,
GTC23R,
GTC25R,
GTC27R,
GTC29R,
GTC31R
0,
1,
2,
3,
4,
5,
6,
7,
8,
9,
10,
11,
12,
13,
14,
15
rw Global Timer Cell k Redirection
0
B
No redirection of GTC service requests.
1
B
Redirection of GTC service request to LTC
service request groups (see Page 24-113).
