TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-232 V2.0, 2007-07

GPTA, V2.0

Table 24-22 lists the interrupt requests used by LTCA2.

Table 24-22 LTCA2 Service Request Groups

Service

Request Group

Number

Source 1 Source 2 Source 3 Source 4

00 LTC00 LTC01 LTC02 LTC03

01 LTC04 LTC05 LTC06 LTC07

02 LTC08 LTC09 LTC10 LTC11

03 LTC12 LTC13 LTC14 LTC15

04 LTC16 LTC17 LTC18 LTC19

05 LTC20 LTC21 LTC22 LTC23

06 LTC24 LTC25 LTC26 LTC27

07 LTC28 LTC29 LTC30 LTC31

08 LTC32 LTC33 LTC34 LTC35

09 LTC36 LTC37 LTC38 LTC39

10 LTC40 LTC41 LTC42 LTC43

11 LTC44 LTC45 LTC46 LTC47

12 LTC48 LTC49 LTC50 LTC51

13 LTC52 LTC53 LTC54 LTC55

14 LTC56 LTC57 LTC58 LTC59

15 LTC60 LTC61 LTC62 LTC63
