TC1796
Peripheral Units (Vol. 2 of 2)
General Purpose Timer Array (GPTA)
User’s Manual 24-238 V2.0, 2007-07
GPTA, V2.0
The Multiplexer Register Array Data In register is used to write data to the Multiplexer
Register Array FIFO. The Multiplexer Register Array Data Out register is used to read
data from the Multiplexer Register Array FIFO.
Note: For correct operation, the MRADIN and MRADIN registers must be always read
or written 32-bit wide. 8-bit and 16-bit accesses are ignored without any bus error!
MRADIN
Multiplexer Register Array Data In Register
(03C
H
) Reset Value: 0000 0000
H
31 0
DATAIN
w
Field Bits Type Description
DATAIN [31:0] w FIFO Write Data
This register contains the FIFO write data as defined
for the Output Multiplexer Control Registers and the
LTC Input Multiplexer Control Registers.
MRADOUT
Multiplexer Register Array Data Out Register
(040
H
) Reset Value: 0000 0000
H
31 0
DATAOUT
rh
Field Bits Type Description
DATAOUT [31:0] rh FIFO Read Data
This register contains the FIFO read data as assigned
for the Output Multiplexer Control Registers and the
LTC Input Multiplexer Control Registers.
