TC1796

Peripheral Units (Vol. 2 of 2)

Analog-to-Digital Converter (ADC)

User’s Manual 25-20 V2.0, 2007-07

ADC, V2.0

Table 25-5 shows the actions to be taken on a change of the auto-scan arbitration

participation flag.

Table 25-5 Change of the Auto-Scan Arbitration Participation Flag AP.ASP

Current Value

of ASP

Write to ASP Action

00No action

1 No action

10In case of bit field CON.SCNM = 00

, 01

, or 11

Bit field SCNM is cleared.

Finish currently performed auto-scan conversion.

Generate a service request (if enabled) if this was the

last channel of auto-scan sequence.

In case of bit field CON.SCNM = 10

Finish currently performed auto-scan conversion and

generate a service request (if enabled) if this was the

last channel of auto-scan sequence.

Start new continuous auto-scan sequence

1Don’t care
