TC1796

Peripheral Units (Vol. 2 of 2)

Analog-to-Digital Converter (ADC)

User’s Manual 25-64 V2.0, 2007-07

ADC, V2.0

Note: The former contents of a CHSTATn register are overwritten with the new result for

the same channel.

CRS [22:20] rh Conversion Request Source

This bit field indicates for channel n the origin of the

conversion result, stored in bit field RESULT.

000

Channel injection

001

Timer

010

Synchronized injection

011

External event

100

Software SW0

101

Reserved

110

Queue

111

Auto-Scan

CHNR [27:24] rh Channel Number

This bit field holds the channel number n.

0 [15:12],

19,23,

[31:28]

r Reserved

Read as 0.

Field Bits Type Description

Table of Contents9
