TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-63 V2.0, 2007-07
ADC, V2.0
CHSTATm (m = 0-15)
Channel Status Register m (130
H
+m*4) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0 CHNR 0 CRS 0
GRP
S
EMUX
rrhrrhrrhrh
1514131211109876543210
0RESULT
rrh
Field Bits Type Description
RESULT [11:0] rh Result of the Last Conversion
This bit field contains the left aligned conversion result
of the last conversion of channel n.
8-bit: Conversion result is stored in RESULT[11:4]
10-bit: Conversion result is stored in RESULT[11:2]
12-bit: Conversion result is stored in RESULT[11:0]
Unused bits of RESULT are 0.
EMUX [17:16] rh Status of External Multiplexer
This bit field indicates the setting of the external
multiplexer control of DMA channel n. This
information is either derived from CHCONn.EMUX
(parallel conversion request sources) or from
CHIN.EMUX and QUEUE.EMUX (sequential
conversion request sources).
GRPS 18 rh Status of Analog Input Multiplexer Group Select
This bit indicates the status of the analog input
multiplexer group select bit for analog input
channel n.
