TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-62 V2.0, 2007-07
ADC, V2.0
ENCH 23 rw Enable Channel Service Request Generation
This bit enables the generation of a channel service
request at the end of a channel conversion.
0
B
The channel service request generation is
disabled.
1
B
The channel service request generation is
enabled.
INP [26:24] rw Interrupt Node Pointer
This bit field selects which service request output line will
be activated if the channel conversion is finished and the
channel service request generation is enabled.
000
B
Service request line SR0 selected
001
B
Service request line SR1 selected
010
B
Service request line SR2 selected
011
B
Service request line SR3 selected
100
B
Service request line SR4 selected
101
B
Service request line SR5 selected
110
B
Service request line SR6 selected
111
B
Service request line SR7 selected
SYM [29:28] rw Synchronized Injection Mode
This bit field determines whether channel n can trigger a
synchronized conversion as master. If enabled, a
synchronized conversion will be requested automatically
when channel n is selected for a conversion.
00
B
Synchronized conversions are disabled for analog
channel n.
01
B
Synchronized conversions and sync-wait
functionality is selected for channel n.
10
B
Synchronized conversion and cancel-sync-repeat
functionality is selected for channel n.
11
B
Reserved
0 15,27,
[31:30]
r Reserved
Read as 0; should be written with 0.
Field Bits Type Description
