Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-86 V2.0, 2007-07
ADC, V2.0
STAT
Converter Status Register (1B4
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
SY
MS
IEN
PAR
IEN
REQ
PAR
SY
REQ
SY
0QF QLP
r rhrhrhrhrh r rh rh
1514131211109876543210
BU
SY
SM
PL
CAL AL
DA
TA
VAL
CHTSCC 0 CHNRCC
rh rh rh rh rh rh r rh
Field Bits Type Description
CHNRCC [3:0] rh Number of Channel Currently Converted
This bit field indicates the number of the channel that
is currently converted.
0000
B
Channel 0 is currently converted.
0001
B
Channel 1 is currently converted.
…
B
…
1110
B
Channel 14 is currently converted.
1111
B
Channel 15 is currently converted.
CHTSCC [10:8] rh Trigger Source of Channel Currently Converted
This bit field indicates the origin of a conversion
request that triggered the channel currently
converted.
000
B
Channel Injection
001
B
Timer
010
B
Synchronization injection mode
011
B
External events
100
B
Software SW0
101
B
Reserved
110
B
Queue
111
B
Auto-scan
DATAVAL 11 rh Data Valid
This bit indicates whether conversion data is valid. It
is set when the conversion is finished and cleared one
f
ADC
clock cycle after the next conversion has been
started.
