Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Fast Analog-to-Digital Converter (FADC)
User’s Manual 26-35 V2.0, 2007-07
FADC, V2.0
EN12 10 rw Enable Neighbor Channel Trigger 12
This bit enables the neighbor channel trigger for
channel 2 when a conversion of channel 1 is started.
0
B
No action.
1
B
A trigger will be generated.
EN13 11 rw Enable Neighbor Channel Trigger 13
This bit enables the neighbor channel trigger for
channel 3 when a conversion of channel 1 is started.
0
B
No action.
1
B
A trigger will be generated.
EN20 16 rw Enable Neighbor Channel Trigger 20
This bit enables the neighbor channel trigger for
channel 0 when a conversion of channel 2 is started.
0
B
No action.
1
B
A trigger will be generated.
EN21 17 rw Enable Neighbor Channel Trigger 21
This bit enables the neighbor channel trigger for
channel 1 when a conversion of channel 2 is started.
0
B
No action.
1
B
A trigger will be generated.
EN23 19 rw Enable Neighbor Channel Trigger 23
This bit enables the neighbor channel trigger for
channel 3 when a conversion of channel 2 is started.
0
B
No action.
1
B
A trigger will be generated.
EN30 24 rw Enable Neighbor Channel Trigger 30
This bit enables the neighbor channel trigger for
channel 0 when a conversion of channel 3 is started.
0
B
No action.
1
B
A trigger will be generated.
EN31 25 rw Enable Neighbor Channel Trigger 31
This bit enables the neighbor channel trigger for
channel 1 when a conversion of channel 3 is started.
0
B
No action.
1
B
A trigger will be generated.
Field Bits Type Description
