Fast Analog-to-Digital Converter (FADC)
User’s Manual 26-34 V2.0, 2007-07
FADC, V2.0
The Neighbor Channel Trigger Register NCTR contains the enable bits for the neighbor
channel trigger signal (NCTx) generation (see Page 26-21).
NCTR
Neighbor Channel Trigger Register (18
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
EN
32
EN
31
EN
30
0
EN
23
0
EN
21
EN
20
rrwrwrwrrwrrwrw
1514131211109876543210
0
EN
13
EN
12
0
EN
10
0
EN
03
EN
02
EN
01
0
rrwrwrrwrrwrwrwr
Field Bits Type Description
EN01 1rwEnable Neighbor Channel Trigger 01
This bit enables the neighbor channel trigger for
channel 1 when a conversion of channel 0 is started.
0
B
No action.
1
B
A trigger will be generated.
EN02 2rwEnable Neighbor Channel Trigger 02
This bit enables the neighbor channel trigger for
channel 2 when a conversion of channel 0 is started.
0
B
No action.
1
B
A trigger will be generated.
EN03 3rwEnable Neighbor Channel Trigger 03
This bit enables the neighbor channel trigger for
channel 3 when a conversion of channel 0 is started.
0
B
No action.
1
B
A trigger will be generated.
EN10 8rwEnable Neighbor Channel Trigger 10
This bit enables the neighbor channel trigger for
channel 0 when a conversion of channel 1 is started.
0
B
No action.
1
B
A trigger will be generated.
