TC1796

System Units (Vol. 1 of 2)

Direct Memory Access Controller

User’s Manual 12-18 V2.0, 2007-07

DMA, V2.0

Figure 12-11 Programmable Address Modification - Example 1

In Figure 12-11, 16-bit half-words are transferred from a source memory with an

incrementing source address offset of 10

to a destination memory with decrementing

destination addresses offset of 08

In Figure 12-12, 16-bit half-words are transferred from a source memory with an

incrementing source address offset of 02

to a destination memory with incrementing

destination addresses offset of 04

MCA05690

ADRCRmn Parameters:

SMF = 011

INCS = 1

Source Memory Destination Memory

31 01516

DMA

Moves

....

31 01516

ADRCRmn Parameters:

DMF = 010

INCD = 0

....
