TC1796

System Units (Vol. 1 of 2)

Direct Memory Access Controller

User’s Manual 12-75 V2.0, 2007-07

DMA, V2.0

Note: See Section 12.3.2 on Page 12-98 for the TC1796 specific address range and

address range extension definitions.

SIZE2 [23:21] rw Address Size 2

SIZE2 determines the sub-range size within address

range extension 2.

SLICE3 [28:24] rw Address Slice 3

SLICE3 selects a specific sub-range within address

range extension 3.

SIZE3 [31:29] rw Address Size 3

SIZE3 determines the sub-range size within address

range extension 3.

Field Bits Type Description
