TC1796
System Units (Vol. 1 of 2)
Introduction
User’s Manual 1-50 V2.0, 2007-07
Intro, V2.0
MSC Outputs
FCLP0A
FCLN0
SOP0A
SON0
FCLP1A
FCLN1
SOP1A
SON1
C18
C17
C16
D17
A17
B17
B16
A16
O
O
O
O
O
O
O
O
C V
DDP
LVDS MSC Clock and Data Outputs
2)
MSC0 differential driver clock output
positive A
MSC0 differential driver clock output
negative
MSC0 differential driver serial data output
positive A
MSC0 differential driver serial data output
negative
MSC1 differential driver clock output
positive A
MSC1 differential driver clock output
negative
MSC1 differential driver serial data output
positive A
MSC1 differential driver serial data output
negative
Table 1-3 Pin Definitions and Functions (cont’d)
Symbol Pins I/O Pad
Driver
Class
Power
Supply
Functions
