Remote control commands
R&S
®
RTE
1878User Manual 1326.1032.02 ─ 20
INRange | OORange
In range/Out of range: set the minimum and maximum value of
the range with TRIGger<m>:CXPI:DATA:DMIN and
TRIGger<m>:CXPI:DATA:DMAX.
*RST: OFF
TRIGger<m>:CXPI:DATA:DMAX <DataMax>
Sets the end value of a data type range if TRIGger<m>:CXPI:DATA:DCONdition is
set to INRange or OORange.
Suffix:
<m>
.
1..3
Parameters:
<DataMax>
TRIGger<m>:CXPI:DATA:DMIN <DataMin>
Specifies a data bit pattern, or sets the start value of a pattern range.
Suffix:
<m>
.
1..3
Parameters:
<DataMin>
TRIGger<m>:CXPI:DATA:ICONdition <DataIdxOperator>
Set the condition for the data index value. You can define an exact value or a value
range.
Suffix:
<m>
.
1..3
Parameters:
<DataIdxOperator> EQUal | LTHan | LETHan | GTHan | GETHan | INRange |
RANGe
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less or equal than, Greater Than,
Greater or equal than. These conditions require one pattern to
be set with the corresponding TRIGger<m>:CXPI:DATA:IMIN
command.
INRange = RANGe
In range: Set the minimum and maximum value using
TRIGger<m>:CXPI:DATA:IMIN and TRIGger<m>:CXPI:
DATA:IMAX.
*RST:
INRange
