High-End Timer (N2HET) Module
The format CC{pin number} is also supported.
MSB LSB Description
0 0 0 0 0 Select HET[0]
0 0 0 0 1 Select HET[1]
(Each pin may be selected by writing its number in binary)
1 1 1 1 0 Select HET[30]
1 1 1 1 1 Select HET[31]
Reg* Register select: Selects the register for data comparison and storage
Default: No register (None)
Location: Control field [2:1] except for CNT instruction.
Extended Register Select C[7] is available for ACMP, ADC, ADD, ADM32, AND,
DADM64, ECMP, ECNT, MCMP, MOV32, MOV64, OR, RADM64, SBB, SHFT, SUB,
WCAP, WCAPE instructions.
Register Ext Reg. C[7] C[2] C[1]
A 0 0 0
B 0 0 1
T 0 1 0
None 0 1 1
R 1 0 0
S 1 0 1
Reserved 1 1 0
Reserved 1 1 1
Action* (2 Action Option) Either sets or clears the pin
Default: Clear
Location: Control Field [4]
Action C[4]
Clear 0
Set 1
Action* (4 Action Option) Either sets, clears, pulse high or pulse low on the pin. Set/clear are
single pin actions, pulse high/low include the opposite pin action.
Default: Clear
Location: Control Field [4:3]
Action Action Type C[4] C[3]
Clear Set low on match 0 0
Set Set high on match 1 0
Pulse Low Set low on match + reset to high on Z=1 (opposite action) 0 1
Pulse High Set high on match + reset to low on Z=1 (opposite action) 1 1
