General-Purpose Input/Output (GIO) Module
25.5.4 GIO Interrupt Enable Registers (GIOENASET and GIOENACLR)
The GIOENASET and GIOENACLR registers control which interrupt-capable pins are actually configured
as interrupts. If the interrupt is enabled, the rising edge, falling edge, or both edges on the selected pin
lead to an interrupt request.
25.5.4.1 GIOENASET Register
Figure 25-8 and Table 25-5 describe this register.
NOTE: Enabling Interrupt at the Device Level
The interrupt channel in the Vectored Interrupt Manager (VIM) must be enabled for the
interrupt request to be forwarded to the CPU. Additionally, the ARM CPU (CPSR bit 7 or 6)
must be cleared to respond to interrupt requests (IRQ/FIQ).
Figure 25-8. GIO Interrupt Enable Set Register (GIOENASET) [offset = 10h]
31 24 23 16
GIOENASET 3 GIOENASET 2
R/W-0 R/W-0
15 8 7 0
GIOENASET 1 GIOENASET 0
R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Table 25-5. GIO Interrupt Enable Set Register (GIOENASET) Field Descriptions
Bit Field Value Description
31-24 GIOENASET 3 Interrupt enable for pins GIOD[7:0]
0 Read: The interrupt is disabled.
Write: Writing a 0 to this bit has no effect.
1 Read: The interrupt is enabled.
Write: Enables the interrupt.
23-16 GIOENASET 2 Interrupt enable for pins GIOC[7:0]
0 Read: The interrupt is disabled.
Write: Writing a 0 to this bit has no effect.
1 Read: The interrupt is enabled.
Write: Enables the interrupt.
15-8 GIOENASET 1 Interrupt enable for pins GIOB[7:0]
0 Read: The interrupt is disabled.
Write: Writing a 0 to this bit has no effect.
1 Read: The interrupt is enabled.
Write: Enables the interrupt.
7-0 GIOENASET 0 Interrupt enable for pins GIOA[7:0]
0 Read: The interrupt is disabled.
Write: Writing a 0 to this bit has no effect.
1 Read: The interrupt is enabled.
Write: Enables the interrupt.
