Power Management Module (PMM)
5.4.16 Isolation Diagnostic Status Register (ISODIAGSTAT)
Figure 5-18. Isolation Diagnostic Status Register (ISODIAGSTAT) (offset = C0h)
31 8
Reserved
R-0
4 3 2 1 0
Reserved ISO DIAG[4] ISO DIAG[3] ISO DIAG[2] ISO DIAG[1] ISO DIAG[0]
R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 5-17. Isolation Diagnostic Status Register (ISODIAGSTAT) Field Descriptions
Bit Field Value Description
31-5 Reserved 0 Reads return 0. Writes have no effect.
4-0 ISO DIAG[4-0] Isolation Diagnostic
Each of these bits corresponds to a logic power domain:
Bit 4 for PD6,
Bit 3 for PD5,
Bit 2 for PD4,
Bit 1 for PD3,
Bit 0 for PD2.
Read in User and Privileged Mode. Writes have no effect.
0 Isolation is enabled for corresponding power domain
1 Isolation is disabled for corresponding power domain
