Cyclic Redundancy Check (CRC) Controller Module
18.4.5 CRC Interrupt Enable Reset Register (CRC_INTR)
Figure 18-13. CRC Interrupt Enable Reset Register (CRC_INTR) [offset = 20h]
31 16
Reserved
R-0
15 13 12 11 10 9 8
Reserved CH2_
TIMEOUTENR
CH2_
UNDERENR
CH2_
OVERENR
CH2_
CRCFAILENR
CH2_
CCITENR
R-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0
7 5 4 3 2 1 0
Reserved CH1_
TIMEOUTENR
CH1_
UNDERENR
CH1_
OVERENR
CH1_
CRCFAILENR
CH1_
CCITENR
R-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 18-9. CRC Interrupt Enable Reset Register (CRC_INTR) Field Descriptions
Bit Field Value Description
31-13 Reserved 0 Reads return 0. Writes have no effect.
12 CH2_TIMEOUTENR Channel 2 Timeout Interrupt Enable Reset Bit.
User and Privileged mode (read):
0 Timeout Interrupt is disabled.
1 Timeout Interrupt is enabled.
Privileged mode (write):
0 No effect.
1 Timeout Interrupt is disabled.
11 CH2_UNDERENR Channel 2 Underrun Interrupt Enable Reset Bit.
User and Privileged mode (read):
0 Underrun Interrupt is disabled.
1 Underrun Interrupt is enabled.
Privileged mode (write):
0 No effect.
1 Underrun Interrupt is disabled.
10 CH2_OVERENR Channel 2 Overrun Interrupt Enable Reset Bit.
User and Privileged mode (read):
0 Overrun Interrupt is disabled.
1 Overrun Interrupt is enabled.
Privileged mode (write):
0 No effect.
1 Overrun Interrupt is disabled.
9 CH2_CRCFAILENR Channel 2 CRC Compare Fail Interrupt Enable Reset Bit.
User and Privileged mode (read):
0 CRC Fail Interrupt disabled.
1 CRC Fail Interrupt is enabled.
Privileged mode (write):
0 No effect.
1 CRC Fail Interrupt is disabled.
