High-End Timer (N2HET) Module
23.5 HWAG Registers
Table 23-51 lists the HWAG registers.
Table 23-51. HWAG Registers
Offset Acronym Register Description Section
9Ch HWAPINSEL HWAG Pin Select Register Section 23.5.1
A0h HWAGCR0 HWAG Global Control Register 0 Section 23.5.2
A4h HWAGCR1 HWAG Global Control Register 1 Section 23.5.3
A8h HWAGCR2 HWAG Global Control Register 2 Section 23.5.4
ACh HWAENASET HWAG Interrupt Enable Set Register Section 23.5.5
B0h HWAENACLR HWAG Interrupt Enable Clear Register Section 23.5.6
B4h HWALVLSET HWAG Interrupt Level Set Register Section 23.5.7
B8h HWALVLCLR HWAG Interrupt Level Clear Register Section 23.5.8
BCh HWAFLG HWAG Interrupt Flag Register Section 23.5.9
C0h HWAOFF0 HWAG Interrupt Offset Register 1 Section 23.5.10
C4h HWAOFF1 HWAG Interrupt Offset Register 2 Section 23.5.11
C8h HWAACNT HWAG Angle Value Register Section 23.5.12
CCh HWAPCNT1 HWAG Previous Tooth Period Value Register Section 23.5.13
D0h HWAPCNT HWAG Current Tooth Period Value Register Section 23.5.14
D4h HWASTWD HWAG Step Width Register Section 23.5.15
D8h HWATHNB HWAG Teeth Number Register Section 23.5.16
DCh HWATHVL HWAG Current Teeth Number Register Section 23.5.17
E0h HWAFIL HWAG Filter Register Section 23.5.18
E8h HWAFIL2 HWAG Filter Register 2 Section 23.5.19
F0h HWAANGI HWAG Angle Increment Register Section 23.5.20
