Texas Instruments TMS570LC4357 User Manual

www.ti.com PMM Registers
299
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Power Management Module (PMM)
5.4.15 LogicPD PSCON Diagnostic Compare Status Register 2 (LPDDCSTAT2)
Figure 5-17. LogicPD PSCON Diagnostic Compare Status Register 2 (LPDDCSTAT2) (offset = B4h)
31 24
Reserved
R-0
23 21 20 19 18 17 16
Reserved LSTET[4] LSTET[3] LSTET[2] LSTET[1] LSTET[0]
R-0 R-0 R-0 R-0 R-0 R-0
15 8
Reserved
R-0
7 5 4 3 2 1 0
Reserved LSTE[4] LSTE[3] LSTE[2] LSTE[1] LSTE[0]
R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 5-16. LogicPD PSCON Diagnostic Compare Status Register 2 (LPDDCSTAT2)
Field Descriptions
Bit Field Value Description
31-21 Reserved 0 Reads return 0. Writes have no effect.
20-16 LSTET[4-0] Logic Power Domain Self-test Error Type
Each of these bits corresponds to a logic power domain:
Bit 4 for PD6,
Bit 3 for PD5,
Bit 2 for PD4,
Bit 1 for PD3,
Bit 0 for PD2.
Read in User and Privileged Mode. Writes have no effect.
0 Self-test failed during compare match test.
1 Self-test failed during compare mismatch test.
15-5 Reserved 0 Reads return 0. Writes have no effect.
4-0 LSTE[4-0] Logic Power Domain Self-test Error
Each of these bits corresponds to a logic power domain:
Bit 4 for PD6,
Bit 3 for PD5,
Bit 2 for PD4,
Bit 1 for PD3,
Bit 0 for PD2.
Read in User and Privileged Mode. Writes have no effect.
0 Self-test passed.
1 Self-test failed.
