HWAG Registers

1045

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

23.5.1 HWAG Pin Select Register (HWAPINSEL)

Figure 23-89. HWAG Pin Select Register (HWAPINSEL)

31 16

Reserved

R-0

15 5 4 0

Reserved PINSEL

R-0 R/W-2h

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 23-52. HWAG Pin Select Register (HWAPINSEL) Field Descriptions

Bit Field Value Description

31-5 Reserved 0 Reads return 0. Writes have no effect.

4-0 PINSEL

HWAG Pin Select. Selects from which NHET pin input buffer the HWAG toothed-wheel signal is

derived.

0 Read: Pin HET[0] is selected.

Write: Selects pin HET[0].

1h Read: Pin HET[1] is selected

Write: Selects pin HET[1].

2h Read: Pin HET[2] is selected

Write: Selects pin HET[2]. Default after reset for backwards compatibility

: :

1Fh Read: Pin HET[31] selected

Write: Selects pin HET[31].
