Error Signaling Module (ESM)
16.4.21 ESM Interrupt Level Set/Status Register 4 (ESMILSR4)
This register is dedicated for Group1 Channel[63:32].
Figure 16-31. ESM Interrupt Level Set/Status Register 4 (ESMILSR4) [offset = 50h]
31 16
INTLVLSET[63:48]
R/WP-0
15 0
INTLVLSET[47:32]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privileged mode only; -n = value after reset
Table 16-23. ESM Interrupt Level Set/Status Register 4 (ESMILSR4) Field Descriptions
Bit Field Value Description
63-32 INTLVLSET Set interrupt level.
Read in User and Privileged mode. Write in Privileged mode only.
0 Read: Read: Interrupt of channel x is mapped to low-level interrupt line.
Write: Leaves the bit and the corresponding clear bit in the ESMILCR4 register unchanged.
1 Read: Interrupt of channel x is mapped to high-level interrupt line.
Write: Maps interrupt of channel x to high-level interrupt line and sets the corresponding clear bit in
the ESMILCR4 register.
16.4.22 ESM Interrupt Level Clear/Status Register 4 (ESMILCR4)
This register is dedicated for Group1 Channel[63:32].
Figure 16-32. ESM Interrupt Level Clear/Status Register 4 (ESMILCR4) [offset = 54h]
31 16
INTLVLCLR[63:48]
R/WP-0
15 0
INTLVLCLR[47:32]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privileged mode only; -n = value after reset
Table 16-24. ESM Interrupt Level Clear/Status Register 4 (ESMILCR4) Field Descriptions
Bit Field Value Description
63-32 INTLVLCLR Clear interrupt level.
Read in User and Privileged mode. Write in Privileged mode only.
0 Read: Interrupt of channel x is mapped to low-level interrupt line.
Write: Leaves the bit and the corresponding set bit in the ESMILSR4 register unchanged.
1 Read: Interrupt of channel x is mapped to high-level interrupt line.
Write: Maps interrupt of channel x to low-level interrupt line and clears the corresponding set bit in
the ESMILSR4 register.
