Error Profiling Controller (EPC)
12.4.10 CAM Index Registers (CAM_INDEX[0-7])
Figure 12-11. CAM Index Registers (CAM_INDEXn) (offset = 200h-21Ch)
31 28 27 24 23 20 19 16
Reserved index n × 4 + 3 Reserved index n × 4 + 2
R-0 R/WP-5h R-0 R/WP-5h
15 12 11 8 7 4 3 0
Reserved index n × 4 + 1 Reserved index n × 4
R-0 R/WP-5h R-0 R/WP-5h
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after synchronous reset on system reset
Table 12-11. CAM Index Registers (CAM_INDEXn) Field Descriptions
Field Value Description
Reserved 0 Reserved. Reads return 0.
index n Entry valid tag for index n. See Table 12-12. This is the 4-bit key that determines whether the current
entry in CAM is occupied or not. A write (privilege mode) to A0h to 11Ch in diagnostic mode or
functional mode does not only update the CAM content in corresponding index but also updates the
corresponding bit field in the entry valid tags registers CAM_INDEXn.
The index has a self correction mechanism as follows:
• Key active if valid key = 1010 or 1011 or 1000 or 1110 or 0010
• Key inactive if valid key = 0101 or 0100 or 0111 or 1101 or 0001
Read:
5h Entry is clear and available for future CAM usage.
Ah Entry is occupied.
All other values Reserved
Write in Diagnostic Mode:
5h Entry is cleared and available for future CAM usage.
Ah Entry is set and occupied.
All other values Reserved
Write in Functional Mode:
5h Entry is cleared and available for future CAM usage.
All other values Reserved
Table 12-12. CAM Index Register n
Address Offset CAM Index Register
CAM Index Register Bits
Bits 27-24 Bits 19-16 Bits 11-8 Bits 3-0
200h CAM Index Register 0 index 3 index 2 index 1 index 0
204h CAM Index Register 1 index 7 index 6 index 5 index 4
208h CAM Index Register 2 index 11 index 10 index 9 index 8
20Ch CAM Index Register 3 index 15 index 14 index 13 index 12
210h CAM Index Register 4 index 19 index 18 index 17 index 16
214h CAM Index Register 5 index 23 index 22 index 21 index 20
218h CAM Index Register 6 index 27 index 26 index 25 index 24
21Ch CAM Index Register 7 index 31 index 30 index 29 index 28
