HWAG Registers
www.ti.com
1046
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer (N2HET) Module
23.5.2 HWAG Global Control Register 0 (HWAGCR0)
Figure 23-90. HWAG Global Control Register 0 (HWAGCR0)
31 16
Reserved
R-0
15 1 0
Reserved RESET
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-53. HWAG Global Control Register 0 (HWAGCR0) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reads return 0. Writes have no effect.
0 RESET HWAG Module Reset.
0 HWAG module is reset.
1 HWAG module is not in reset.
23.5.3 HWAG Global Control Register 1 (HWAGCR1)
Figure 23-91. HWAG Global Control Register 1 (HWAGCR1)
31 16
Reserved
R-0
15 1 0
Reserved PPWN
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-54. HWAG Global Control Register 1 (HWAGCR1) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reads return 0. Writes have no effect.
0 PPWN 0 HWAG Module Power Down. This bit is implemented for legacy purposes, but has no functionality,
however the HWAG module power down is controlled by the NHET power down. The HWAG
cannot be powered down separately.
