ADC Registers
www.ti.com
938
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Analog To Digital Converter (ADC) Module
22.3.54 ADC Magnitude Compare Interrupt Control Registers (ADMAGINTxCR)
ADC Magnitude Compare Interrupt Control Registers (ADMAGINTxCR) are shown in Figure 22-83 and
Figure 22-84, and described in Table 22-60. As shown, the format of the ADMAGINTxCR is different
based on whether the ADC module is configured to be a 12-bit or a 10-bit ADC module. The ADC module
supports up to three magnitude compare interrupts. These registers are at offset addresses 128h, 130h,
and 138h.
Figure 22-83. 12-bit ADC Magnitude Compare Interrupt Control Registers (ADMAGINTxCR)
[offset = 128h-138h]
31 28 27 16
Reserved MAG_THRx
R-0 R/W-0
15 14 13 12 8
CHN_THR_
COMPx
CMP_GE_LTx Reserved COMP_CHIDx
R/W-0 R/W-0 R-0 R/W-0
7 5 4 0
Reserved MAG_CHIDx
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 22-84. 10-bit ADC Magnitude Compare Interrupt Control Registers (ADMAGINTxCR)
[offset = 128h-138h]
31 30 26 25 16
Rsvd MAG_CHIDx MAG_THRx
R-0 R/W-0 R/W-0
15 13 12 8
Reserved COMP_CHIDx
R-0 R/W-0
7 2 1 0
Reserved CHN_THR_
COMPx
CMP_GE_LTx
R-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
