DCC Control Registers

www.ti.com

554

SPNU563A–March 2018

Submit Documentation Feedback

Dual-Clock Comparator (DCC) Module

15.4.7 DCC Counter0 Value Register (DCCCNT0)

Figure 15-13 and Table 15-8 describe the DCC Counter0 Value register.

Figure 15-13. DCC Counter0 Value Register (DCCCNT0) [offset = 18h]

31 20 19 16

Reserved COUNT0

R-0 R-0

15 0

COUNT0

R-0

LEGEND: R = Read only; -n = value after reset

Table 15-8. DCC Counter0 Value Register (DCCCNT0) Field Descriptions

Bit Field Value Description

31-20 Reserved 0 Reads return 0. Writes have no effect.

19-0 COUNT0 Current value of DCC counter0.

Reads in any operating mode return the current value of counter0.

Writes have no effect.

NOTE: Reads may not return exact current value of counter

Reading the counter0 value while counting is enabled may not return the exact value of the

counter0.
