HWAG Registers
www.ti.com
1058
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer (N2HET) Module
23.5.18 HWAG Filter Register (HWAFIL)
Figure 23-106. HWAG Filter Register (HWAFIL)
31 16
Reserved
R-0
15 10 9 0
Reserved FIL1
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-70. HWAG Filter Register (HWAFIL) Field Descriptions
Bit Field Value Description
31-10 Reserved 0 Reads return 0. Writes have no effect.
9-0 FIL1 0-3FFh Filter Value. Contains the value to be compared to the tick counter. It allows the tooth signal
to be taken into account by the HWAG. This function works only if the mode filtering is set.
The value is calculated as shown in Section 23.3.2.2.5.
23.5.19 HWAG Filter Register 2 (HWAFIL2)
Figure 23-107. HWAG Filter Register 2 (HWAFIL2)
31 16
Reserved
R-0
15 12 11 0
Reserved FIL2
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 23-71. HWAG Filter Register 2 (HWAFIL2) Field Descriptions
Bit Field Value Description
31-12 Reserved 0 Reads return 0. Writes have no effect.
11-0 FIL2 0-FFFh Filter Value 2. Contains the value to be compared to the tick counter during the singularity
tooth. It allows the tooth signal to be taken into account by the HWAG. This function works
only if the mode filtering is set. The value is calculated as shown in Section 23.3.2.2.5.1.
