Control of Special Multiplexed Options
315
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
I/O Multiplexing and Control Module (IOMM)
Table 6-5. ADC2 Trigger Event Selection
Group Source
Select, G1SRC,
G2SRC or EVSRC
Event # PINMMR161[0] PINMMR161[1] Control Option A Control Option B Trigger Source
000 1 x x NA NA AD2EVT
001 2 1 0 PINMMR162[16] = x PINMMR162[17] = x N2HET1[8]
0 1 PINMMR162[16] = 1 PINMMR162[17] = 0 N2HET2[5]
0 1 PINMMR162[16] = 0 PINMMR162[17] = 1 ePWM_B
010 3 1 0 NA NA N2HET1[10]
0 1 NA NA N2HET1[27]
011 4 1 0 PINMMR162[24] = x PINMMR162[25] = x RTI1 Comp0
0 1 PINMMR162[24] = 1 PINMMR162[25] = 0 RTI1 Comp0
0 1 PINMMR162[24] = 0 PINMMR162[25] = 1 ePWM_A1
100 5 1 0 NA NA N2HET1[12]
0 1 NA NA N2HET1[17]
101 6 1 0 PINMMR163[0] = x PINMMR163[1] = x N2HET1[14]
0 1 PINMMR163[0] = 1 PINMMR163[1] = 0 N2HET1[19]
0 1 PINMMR163[0] = 0 PINMMR163[1] = 1 N2HET2[1]
110 7 1 0 PINMMR163[8] = x PINMMR163[9] = x GIOB[0]
0 1 PINMMR163[8] = 1 PINMMR163[9] = 0 N2HET1[11]
0 1 PINMMR163[8] = 0 PINMMR163[9] = 1 ePWM_A2
111 8 1 0 PINMMR163[16] = x PINMMR163[17] = x GIOB[1]
0 1 PINMMR163[16] = 1 PINMMR163[17] = 0 N2HET2[13]
0 1 PINMMR163[16] = 0 PINMMR163[17] = 1 ePWM_AB
6.5.5 Control for ADC Event Trigger Signal Generation from ePWMx Modules
This microcontroller implements 7 ePWM modules, see Figure 6-4. Each of these modules generate two
outputs, SOCA (Start Of Conversion) and SOCB, for use in triggering the on-chip ADC modules. Registers
from the I/O multiplexing module are used to control the logic for generation of the ePWM_A1, ePWM_A2,
ePWM_AB, and ePWM_B signals from these ePWMx_SOCA and ePWMx_SOCB signals.
