Error Signaling Module (ESM)
16.4.9 ESM Status Register 3 (ESMSR3)
This register is dedicated for Group3.
Figure 16-19. ESM Status Register 3 (ESMSR3) [offset = 20h]
31 16
ESF3[31:0]
R/W1CP-X/0
15 0
ESF3[15:0]
R/W1CP-X/0
LEGEND: R/W = Read/Write; W1CP = Write 1 to clear in privilege mode only; -n = value after reset/PORRST; X = value is unchanged
Table 16-11. ESM Status Register 3 (ESMSR3) Field Descriptions
Bit Field Value Description
31-0 ESF3 Error Status Flag. Provides status information on a pending error.
Read in User and Privileged mode. Write in Privileged mode only.
0 Read: No error occurred.
Write: Leaves the bit unchanged.
1 Read: Error occurred.
Write: Clears the bit.
16.4.10 ESM ERROR Pin Status Register (ESMEPSR)
Figure 16-20. ESM ERROR Pin Status Register (ESMEPSR) [offset = 24h]
31 16
Reserved
R-0
15 1 0
Reserved EPSF
R-0 R-X/1
LEGEND: R = Read only; -n = value after reset/PORRST; X = value is unchanged
Table 16-12. ESM ERROR Pin Status Register (ESMEPSR) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reads return 0. Writes have no effect.
0 EPSF ERROR Pin Status Flag. Provides status information for the ERROR Pin.
Read/Write in User and Privileged mode.
0 Read: ERROR pin is low (active) if any error has occurred.
Write: Writes have no effect.
1 Read: ERROR pin is high if no error has occurred.
Write: Writes have no effect.
Note: This flag will be set to 1 after PORRST. The value will be unchanged after RST. The ERROR
pin status remains unchanged during after RST.
