PMM Registers
287
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Power Management Module (PMM)
5.4.2 Logic Power Domain Control Register (LOGICPDPWRCTRL1)
The default values of the control fields are determined by the device reset configuration word stored in the
TI-OTP region of flash bank 0.
Figure 5-4. Logic Power Domain Control Register (LOGICPDPWRCTRL1) (offset = 04h)
31 28 27 24 23 16
Reserved LOGICPDON4 Reserved
R-0 R/WP-n R-0
15 0
Reserved
R-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 5-3. Logic Power Domain Control Register (LOGICPDPWRCTRL1) Field Descriptions
Bit Field Value Description
31-28 Reserved 0 Reads return 0. Writes have no effect.
27-24 LOGICPDON4 Read in User and Privileged Mode. Write in Privileged Mode only.
Ah Read: Power domain PD6 is in OFF state.
Write: Power domain PD6 is commanded to switch to OFF state.
9h Reserved
Any other value Read: Power domain PD6 is in Active state.
Write: Power domain PD6 is commanded to switch to Active state.
23-0 Reserved 0 Reads return 0. Writes have no effect.
