www.ti.com
HTU Control Registers
1169
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer Transfer Unit (HTU) Module
24.4.25 Parity Address Register (HTU PAR)
Figure 24-38. Parity Address Register (HTU PAR) [offset = 68h]
31 17 16
Reserved PEFT
R-0 R/W1CP-0
15 9 8 0
Reserved PAOFF
R-0 R-X
LEGEND: R/W = Read/Write; R = Read only; W1CP = Write 1 in privilege mode to clear the bit; -n = value after reset; X = undefined
Table 24-38. Parity Address Register (HTU PAR) Field Descriptions
Bit Field Value Description
31-10 Reserved 0 Reads return 0. Writes have no effect.
16 PEFT Parity Error Fault Flag. This bit is set, when the HTU detects a parity error and parity checking is
enabled.
0 No fault is detected.
1 Fault is detected.
Note: Once PEFT is set, a read access to the lower 16 bits or to the complete 32-bit HTUPAR register
will clear the PEFT flag in non-debug mode. Another possibility to clear PEFT is to write a 1 to the
PEFT bit.
15-9 Reserved 0 Reads return 0. Writes have no effect.
8-0 PAOFF Parity Error Address Offset. This bit field holds the address of the first parity error, which is detected in
the DCP RAM. PAOFF provides the offset address of the erroneous byte counted from the beginning of
the DCP memory. This error address is frozen from being updated until a read access to the lower 16
bits or to the complete 32-bit HTUPAR register happens. During debug mode, this address is frozen
even when read.
Note: The Parity Error Address bits will not be reset, neither by PORRST nor by any other reset source.
