VIM Control Registers
www.ti.com
686
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Vectored Interrupt Manager (VIM) Module
19.9.9 FIQ/IRQ Program Control Registers (FIRQPR[0:3])
The FIQ/IRQ program control registers determine whether a given interrupt request will be either FIQ or
IRQ. Figure 19-19, Figure 19-20, Figure 19-21, Figure 19-22 and Table 19-14 describe these registers.
NOTE: Channel 0 and 1 are FIQ only, not impacted by this register.
Figure 19-19. FIQ/IRQ Program Control Register 0 (FIRQPR0) [offset = 10h]
31 16
FIRQPR0[31:16]
R/WP-0
15 2 1 0
FIRQPR0[15:2] Reserved
R/WP-0 R-3h
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset
Figure 19-20. FIQ/IRQ Program Control Register 1 (FIRQPR1) [offset = F14h]
31 0
FIRQPR1[63:32]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Figure 19-21. FIQ/IRQ Program Control Register 2 (FIRQPR2) [offset = 18h]
31 0
FIRQPR2[95:64]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Figure 19-22. FIQ/IRQ Program Control Register 3 (FIRQPR3) [offset = 1Ch]
31 0
FIRQPR3[127:96]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 19-14. FIQ/IRQ Program Control Registers (FIRQPR) Field Descriptions
Bit Field Value Description
127-2 FIRQPRx[n] FIQ/IRQ program control bits. These bits determine whether an interrupt request from a peripheral
is of type FIQ or IRQ. Bit FIRQPRx[127:2] corresponds to request channel[127:2].
0 Interrupt request is of IRQ type.
1 Interrupt request is of FIQ type.
1-0 Reserved 3h Read only. Writes have no effect.
