Double Control Packet Configuration Memory
www.ti.com
1180
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer Transfer Unit (HTU) Module
24.5.7 Current Frame Count Register (HTU CFCOUNT)
The current frame count register enables the software to find out the recent frame in the buffer while the
counter of the active buffer decrements.
Figure 24-48. Current Frame Count Register (HTU CFCOUNT)
31 24 23 16
Reserved CFTCTA
R-0 R/WP-X
15 8 7 0
Reserved CFTCTB
R-0 R/WP-X
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset; X = Unknown
Table 24-49. Current Frame Count Register (HTU CFCOUNT) Field Descriptions
Bit Field Value Description
31-24 Reserved 0 Reads return 0. Writes have no effect.
23-16 CFTCTA Current Frame Transfer Count for CP A. It is updated at the end of each frame.
15-8 Reserved 0 Reads return 0. Writes have no effect.
7-0 CFTCTB Current Frame Transfer Count for CP B. It is updated at the end of each frame.
