Vectored Interrupt Manager (VIM) Module
19.9.14 Wake-Up Enable Clear Registers (WAKEENACLR[0:3])
The wake-up enable register selectively disables individual wake-up interrupt request lines. Figure 19-39,
Figure 19-40, Figure 19-41, Figure 19-42 and Table 19-19 describe these registers.
Figure 19-39. Wake-Up Enable Clear Register 0 (WAKEENACLR0) [offset = 60h]
31 0
WAKEENACLR0[31:0]
R/WP-FFFF FFFFh
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Figure 19-40. Wake-Up Enable Clear Register 1 (WAKEENACLR1) [offset = 64h]
31 0
WAKEENACLR1[63:32]
R/WP-FFFF FFFFh
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Figure 19-41. Wake-Up Enable Clear Register 2 (WAKEENACLR2) [offset = 68h]
31 0
WAKEENACLR2[95:64]
R/WP-FFFF FFFFh
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Figure 19-42. Wake-Up Enable Clear Register 3 (WAKEENACLR3) [offset = 6Ch]
31 0
WAKEENACLR3[127:96]
R/WP-FFFF FFFFh
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 19-19. Wake-Up Enable Clear Registers (WAKEENACLR) Field Descriptions
Bit Field Value Description
127-0 WAKEENACLRx[n] Wake-up enable clear bits. This vector determines whether the wake-up interrupt line is
enabled. Bit WAKEENACLRx[127:0] corresponds to interrupt request channel[127:0].
0 Read: Wake-up interrupt channel is disabled.
Write: No effect.
1 Read: The wake-up interrupt channel is enabled.
Write: The wake-up interrupt channel is disabled.
