PBIST Control Registers
423
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Programmable Built-In Self-Test (PBIST) Module
9.5.11 ROM Algorithm Mask Register (ALGO)
This register is used to indicate the algorithm(s) to be used for the memory self-test routine. Each bit
corresponds to a specific algorithm. For example, bit [0] controls whether algorithm 1 is enabled or not.
Figure 9-16 and Table 9-15 illustrate this register.
Figure 9-16. ROM Algorithm Mask Register (ALGO) [offset = 01C4h]
31 24 23 16
ALGO3 ALGO2
R/W-FFh R/W-FFh
15 8 7 0
ALGO1 ALGO0
R/W-FFh R/W-FFh
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 9-15. Algorithm Mask Register (ALGO) Field Descriptions
Bit Field Value Description
31 0 Algorithm 32 is not selected.
1 Selects algorithm 32 for PBIST run.
30 0 Algorithm 31 is not selected.
1 Selects algorithm 31 for PBIST run.
: :
0 0 Algorithm 1 is not selected.
1 Selects algorithm 1 for PBIST run.
31-0 0 None of the algorithms are selected.
NOTE: Please refer to Table 2-6 for available algorithms and the memories on which each algorithm
can be run.
