Self-Test Controller (STC) Module
10.8.6 Self-Test Global Status Register (STCGSTAT)
This register is described in Figure 10-13 and Table 10-14.
NOTE: The two status bits can be cleared to their default values on a write of 1 to the bits.
Additionally when the STC_ENA key in STCGCR1 is written from a disabled state to an
enabled state, the two status flags get cleared to their default values. This register gets reset
to its default value with power-on reset assertion.
Figure 10-13. Self-Test Global Status Register (STCGSTAT) [offset = 14h]
31 16
Reserved
R-0
15 12 11 8 7 2 1 0
Reserved ST_ACTIVE Reserved TEST_FAIL TEST_DONE
R-0 R-5h R-0 R/W1CP-0 R/W1CP-0
LEGEND: R/W = Read/Write; R = Read only; W1CP = Write 1 to clear in privilege mode; -n = value after reset
Table 10-14. Self-Test Global Status Register (STCGSTAT) Field Descriptions
Bit Field Value Description
31-12 Reserved 0 Reads return 0. Writes have no effect.
11-8 ST_ACTIVE This field indicates if the self-test is active.
Ah Self-test is active.
All other values Self-test is not active.
This will be set in the cycle after CORE_SEL is programmed. This will be reset once the STC
generated the CPU reset after completion of the self-test.
7-2 Reserved 0 Reads return 0. Writes have no effect.
1 TEST_FAIL Test Fail
0 Self-test run has not failed.
1 Self-test run has failed.
0 TEST_DONE Test Done
0 Self-test run is not completed.
1 Self-test run is completed.
The test done flag is set to a 1 for any of the following conditions:
1. When the STC run is complete without any failure
2. When a failure occurs on a STC run
3. When a timeout failure occurs
Reset is generated to the CPU on which the STC run is being performed when TEST_DONE
goes high (the test is completed).
