21.3.10 EMIF Interrupt Mask Set Register (INTMSKSET)
The EMIF interrupt mask set register (INTMSKSET) is used to enable the Asynchronous Timeout
Interrupt. If read as 1, the AT_MASKED bit in the EMIF interrupt masked register (INTMSK) will be set and
an interrupt will be generated when an Asynchronous Timeout occurs. If read as 0, the AT_MASKED bit
will always read 0 and no interrupt will be generated when an Asynchronous Timeout occurs. Writing a 1
to the AT_MASK_SET bit enables the Asynchronous Timeout Interrupt. The EMIF on some devices does
not have the EMIF_nWAIT pin; therefore, these registers and fields are reserved on those devices. The
INTMSKSET is shown in Figure 21-24 and described in Table 21-34.
Figure 21-24. EMIF Interrupt Mask Set Register (INTMSKSET) [offset = 48h]
31 16
Reserved
R-0
15 3 2 1 0
Reserved WR_MASK_SET LT_MASK_SET AT_MASK_SET
R-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 21-34. EMIF Interrupt Mask Set Register (INTMSKSET) Field Descriptions
Bit Field Value Description
31-3 Reserved 0 Reserved. The reserved bit location is always read as 0. If writing to this field, always write the
default value of 0.
2 WR_MASK_SET Wait Rise Mask Set. This bit determines whether or not the wait rise Interrupt is enabled. Writing a
1 to this bit sets this bit, sets the WR_MASK_CLR bit in the EMIF interrupt mask clear register
(INTMSKCLR), and enables the wait rise interrupt. To clear this bit, a 1 must be written to the
WR_MASK_CLR bit in INTMSKCLR.
0 Indicates that the wait rise interrupt is disabled. Writing a 0 has no effect.
1 Indicates that the wait rise interrupt is enabled. Writing a 1 sets this bit and the WR_MASK_CLR bit
in the EMIF interrupt mask clear register (INTMSKCLR).
1 LT_MASK_SET Mask set for LT_MASKED bit in the EMIF interrupt mask register (INTMSK).
0 Indicates that the line trap interrupt is disabled. Writing a 0 has no effect.
1 Indicates that the line trap interrupt is enabled. Writing a 1 sets this bit and the LT_MASK_CLR bit
in the EMIF interrupt mask clear register (INTMSKCLR).
0 AT_MASK_SET Asynchronous Timeout Mask Set. This bit determines whether or not the Asynchronous Timeout
Interrupt is enabled. Writing a 1 to this bit sets this bit, sets the AT_MASK_CLR bit in the EMIF
interrupt mask clear register (INTMSKCLR), and enables the Asynchronous Timeout Interrupt. To
clear this bit, a 1 must be written to the AT_MASK_CLR bit of the EMIF interrupt mask clear
register (INTMSKCLR).
0 Indicates that the Asynchronous Timeout Interrupt is disabled. Writing a 0 has no effect.
1 Indicates that the Asynchronous Timeout Interrupt is enabled. Writing a 1 sets this bit and the
AT_MASK_CLR bit in the EMIF interrupt mask clear register (INTMSKCLR).
