www.ti.com ESM Control Registers
571
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Error Signaling Module (ESM)
16.4.11 ESM Interrupt Offset High Register (ESMIOFFHR)
Figure 16-21. ESM Interrupt Offset High Register (ESMIOFFHR) [offset = 28h]
31 16
Reserved
R-0
15 8 7 0
Reserved INTOFFH
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 16-13. ESM Interrupt Offset High Register (ESMIOFFHR) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reads return 0. Writes have no effect.
7-0 INTOFFH Offset High-Level Interrupt. This vector gives the channel number of the highest-pending interrupt
request for the high-level interrupt line. Interrupts of error Group2 have higher priority than
interrupts of error Group1. Inside a group, channel 0 has highest priority and channel 31 has lowest
priority.
User and privileged mode (read):
Returns number of pending interrupt with the highest priority for the high-level interrupt line.
0 No pending interrupt.
1h Interrupt pending for channel 0, error Group1.
: :
20h Interrupt pending for channel 31, error Group1.
21h Interrupt pending for channel 0, error Group2.
: :
40h Interrupt pending for channel 31, error Group2.
41h Interrupt pending for channel 32, error Group1.
: :
60h Interrupt pending for channel 63, error Group1.
61h Reserved
: :
80h Reserved
81h Interrupt pending for channel 64, error Group1.
: :
A0h Interrupt pending for channel 95, error Group1.
Note: Reading the interrupt vector will clear the corresponding flag in the ESMSR2 register; will not
clear ESMSR1 and ESMSSR2 and the offset register gets updated.
User and privileged mode (write):
Writes have no effect.
