HWAG Registers

1049

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

23.5.6 HWAG Interrupt Enable Clear Register (HWAENACLR)

Figure 23-94. HWAG Interrupt Enable Clear Register (HWAENACLR)

31 8

Reserved

R-0

7 6 5 4 3 2 1 0

CLRINTENA7 CLRINTENA6 CLRINTENA5 CLRINTENA4 CLRINTENA3 CLRINTENA2 CLRINTENA1 CLRINTENA0

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 23-58. HWAG Interrupt Enable Clear Register (HWAENACLR) Field Descriptions

Bit Field Value Description

31-8 Reserved 0 Reads return 0. Writes have no effect.

7-0 CLRINTENA[n] Disable interrupt. See Table 23-57.

0 Read: Corresponding interrupt is not enabled.

Write: No effect.

1 Read: Corresponding interrupt is enabled.

Write: Disable corresponding interrupt.
