POM Control Registers

www.ti.com

386

SPNU563A–March 2018

Submit Documentation Feedback

F021 Level 2 Flash Module Controller (L2FMC)

7.11.6 POM Region Size Register (POMREGSIZEx)

Contains the size of the program memory and overlay memory region.

Figure 7-51. POM Region Size Register (POMREGSIZEx) (offset = 208h, 218h, ...)

31 16

Reserved

R-0

15 4 3 0

Reserved SIZE

R-0 R/WP-0

LEGEND: R/W = Read/Write; R = Read only; WP=Write in Privilege Mode; -n = value after reset

Table 7-54. POM Region Size Register (POMREGSIZEx) Field Descriptions

Bit Field Value Description

31-4 Reserved 0 Reads return 0. Writes have no effect.

3-0 SIZE 0 Region is disabled.

1h 64 bytes

2h 128 bytes

: :

Ch 128K bytes

Dh 256K bytes

Eh-Fh Reserved
