I/O Multiplexing and Control Module (IOMM)
6.5.11 Control for Input Connections to eQEPx Modules
Each eQEPx module has four inputs from the device terminals. These inputs can be connected to the
eQEPx module in one of two ways:
1. Double-synchronized using VCLK3
2. Double-synchronized using VCLK3 and then filtered through a 6-VCLK3-cycle counter
Registers in the I/O multiplexing module are used to control these input connections for each eQEPx
module.
Table 6-9. Controls for eQEPx Inputs
eQEPx Input
Control for Double-VCLK3-
Synchronized Input
(default connection)
Control for Double-VCLK3-
Synchronized and
6-VCLK3-Filtered Input
eQEP1A PINMMR170[16] = 1
PINMMR170[16] = 0
PINMMR170[17] = 1
eQEP1B PINMMR170[24] = 1
PINMMR170[24] = 0
PINMMR170[25] = 1
eQEP1I PINMMR171[0] = 1
PINMMR171[0] = 0
PINMMR171[1] = 1
eQEP1S PINMMR171[8] = 1
PINMMR171[8] = 0
PINMMR171[9] = 1
eQEP2A PINMMR171[16] = 1
PINMMR171[16] = 0
PINMMR171[17] = 1
eQEP2B PINMMR171[24] = 1
PINMMR171[24] = 0
PINMMR171[25] = 1
eQEP2I PINMMR172[0] = 1
PINMMR172[0] = 0
PINMMR172[1] = 1
eQEP2S PINMMR172[8] = 1
PINMMR172[8] = 0
PINMMR172[9] = 1
