Power Management Module (PMM)
5.4.14 LogicPD PSCON Diagnostic Compare Status Register 1 (LPDDCSTAT1)
Figure 5-16. LogicPD PSCON Diagnostic Compare Status Register 1 (LPDDCSTAT1) (offset = B0h)
31 24
Reserved
R-0
23 21 20 19 18 17 16
Reserved LCMPE[4] LCMPE[3] LCMPE[2] LCMPE[1] LCMPE[0]
R-0 R/W1CP-0 R/W1CP-0 R/W1CP-0 R/W1CP-0 R/W1CP-0
15 8
Reserved
R-0
7 5 4 3 2 1 0
Reserved LSTC[4] LSTC[3] LSTC[2] LSTC[1] LSTC[0]
R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R/W = Read/Write; R = Read only; W1C = Write 1 to Clear; WP = Write in privileged mode only; -n = value after reset
Table 5-15. LogicPD PSCON Diagnostic Compare Status Register 1 (LPDDCSTAT1)
Field Descriptions
Bit Field Value Description
31-21 Reserved 0 Reads return 0. Writes have no effect.
20-16 LCMPE[4-0] Logic Power Domain Compare Error
Each of these bits corresponds to a logic power domain:
Bit 4 for PD6,
Bit 3 for PD5,
Bit 2 for PD4,
Bit 1 for PD3,
Bit 0 for PD2.
Read in User and Privileged Mode. Write in Privileged mode only.
0 Read: PSCON signals are identical.
Write: Writing 0 has no effect.
1 Read: PSCON signal compare mismatch identified.
Write: Clears the corresponding LCMPE bit, if set.
15-5 Reserved 0 Reads return 0. Writes have no effect.
4-0 LSTC[4-0] Logic Power Domain Self-test Complete
Each of these bits corresponds to a logic power domain:
Bit 4 for PD6,
Bit 3 for PD5,
Bit 2 for PD4,
Bit 1 for PD3,
Bit 0 for PD2.
Read in User and Privileged Mode. Writes have no effect.
0 Self-test is ongoing if self-test mode is entered.
1 Self-test is complete.
