SCM Registers
www.ti.com
262
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
SCR Control Module (SCM)
3.4.3 SCM Compare Threshold Counter Register (SCMTHRESHOLD)
Figure 3-7. SCM Compare Threshold Counter Register (SCMTHRESHOLD) [offset = 08h]
31 16
REQ2RESPONSE_MAX
R/WP-400h
15 0
REQ2ACCEPT_MAX
R/WP-400h
LEGEND: R/W = Read/Write; WP = Write in privileged mode only; -n = value after synchronous reset on system reset
Table 3-4. SCM Compare Threshold Counter Register (SCMTHRESHOLD) Field Descriptions
Bit Field Value Description
31-16 REQ2RESPONSE_MAX 0-FFFFh Request to Response Threshold values. You need to configure the maximum
threshold values for request to response timeout. Reset values equals to the values of
REQ2RESP_RST generic parameter.
Read: Values of counter.
Write in Privilege: Values of counter.
15-0 REQ2ACCEPT_MAX 0-FFFFh Request to Accept Threshold values. You need to configure the maximum threshold
values for request to accept timeout. Reset values equals to the values of
REQ2ACCEPT_RST generic parameter.
Read: Values of counter.
Write in Privilege: Values of counter.
