Level 2 RAM (L2RAMW) Module
8.3.9 L2RAMW Bank to Domain Mapping Register0 (BANK_DOMAIN_MAP0)
The BANK_DOMAIN_MAP0 register, shown in Figure 8-10 and described in Table 8-11, stores the
address for which an address-parity error was detected.
Figure 8-10. L2RAMW Bank to Domain Mapping Register0 (BANK_DOMAIN_MAP0)
(offset = 44h)
31 30 28 27 26 24 23 22 20 19 18 16
Rsvd BANK7_MAP Rsvd BANK6_MAP Rsvd BANK5_MAP Rsvd BANK4_MAP
R-0 R-DS R-0 R-DS R-0 R-DS R-0 R-DS
15 14 12 11 10 8 7 6 4 3 2 0
Rsvd BANK3_MAP Rsvd BANK2_MAP Rsvd BANK1_MAP Rsvd BANK0_MAP
R-0 R-DS R-0 R-DS R-0 R-DS R-0 R-DS
LEGEND: R = Read only; DS = Device Specific; -n = value after reset
Table 8-11. L2RAMW Bank to Domain Mapping Register0 (BANK_DOMAIN_MAP0)
Field Descriptions
Bit Field Value Description
31 Reserved 0 Reads return 0. Writes have no effect.
30-28 BANK7_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 7 is
associated.
27 Reserved 0 Reads return 0. Writes have no effect.
26-24 BANK6_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 6 is
associated.
23 Reserved 0 Reads return 0. Writes have no effect.
22-20 BANK5_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 5 is
associated.
19 Reserved 0 Reads return 0. Writes have no effect.
18-16 BANK4_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 4 is
associated.
15 Reserved 0 Reads return 0. Writes have no effect.
14-12 BANK3_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 3 is
associated.
11 Reserved 0 Reads return 0. Writes have no effect.
10-8 BANK2_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 2 is
associated.
7 Reserved 0 Reads return 0. Writes have no effect.
6-4 BANK1_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 1 is
associated.
3 Reserved 0 Reads return 0. Writes have no effect.
2-0 BANK0_MAP 0-7h This 3-bit field allows the software to read the memory power domain number that bank 0 is
associated.
