Flash Control Registers
www.ti.com
364
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
F021 Level 2 Flash Module Controller (L2FMC)
7.10.10 Flash Bank Protection Register (FBPROT)
Figure 7-20. Flash Bank Protection Register (FBPROT) (offset = 30h)
31 16
Reserved
R-0
15 1 0
Reserved PROTL1DIS
R-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in Privilege Mode; -n = value after reset
Table 7-22. Flash Bank Protection Register (FBPROT) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reads return 0. Writes have no effect.
0 PROTL1DIS Level 1 Protection Disable bit
Setting this bit disables protection from writing to the OTPPROTDIS bits in the FBAC register as
well as the BSE bits for all banks in the FBSE register. Clearing this bit enables protection and
disables write access to the OTPPROTDIS bits and FBSE register.
0 Level 1 protection is enabled.
1 Level 1 protection is disabled.
7.10.11 Flash Bank Sector Enable Register (FBSE)
FBSE provides one enable bit per sector for up to 16 sectors per bank. Each bank in the Flash module
has one FBSE register. The bank is selected via the BANK bits in the FMAC register. As only one bank at
a time can be selected by FMAC, only the register for the bank selected appears at this address.
Figure 7-21. Flash Bank Sector Enable Register (FBSE) (offset = 34h)
31 16
Reserved
R-0
15 0
BSE[15:0]
R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP=Write in Privilege Mode; -n = value after reset
Table 7-23. Flash Bank Sector Enable Register (FBSE) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reads return 0. Writes have no effect.
15-0 BSE[n] Bank Sector Enable. Each bit corresponds to a Flash sector in the bank specified by the FMAC
register. Bit 0 corresponds to sector 0, bit 1 corresponds to sector 1, and so on. These bits can be
set only when PROTL1DIS = 1 in the FBPROT register and in privilege mode.
0 The corresponding numbered sector is disabled for program or erase access.
1 The corresponding numbered sector is enabled for program or erase access.
