HTU Control Registers
www.ti.com
1168
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
High-End Timer Transfer Unit (HTU) Module
24.4.24 Parity Control Register (HTU PCR)
Figure 24-37. Parity Control Register (HTU PCR) [offset = 64h]
31 17 16
Reserved COPE
R-0 R/WP-0
15 9 8 7 4 3 0
Reserved TEST Reserved PARITY_ENA
R-0 R/WP-0 R-0 R/WP-5h
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 24-37. Parity Control Register (HTU PCR) Field Descriptions
Bit Field Value Description
31-17 Reserved 0 Reads return 0. Writes have no effect.
16 COPE Continue on Parity Error
0 The HTU performs parity checks every time it reads the RAM section of DCP x (with x = 0, 1,... or
7), before the next frame (of DCP x) is started. If a parity error is detected during this read access
and if the parity check is enabled, then the frame will not be started and DCP x will be automatically
disabled in the CPENA register.
If a master different than the HTU (for example, CPU) reads the RAM section of DCP x and a parity
error is detected during this read access, while the parity check is enabled, then the DCP x will
automatically be disabled in the CPENA register. If a frame is active on DCP x during this read
access, then in addition the element counter of DCP x is cleared and all new element transfers on
DCP x are stopped and the active busy bit of DCP x is cleared.
1 The difference to COPE = 0 is, that the data transfer on a active DCP continues after a parity error
was detected on this DCP. So, neither the DCP with the parity error will be disabled nor the frame
will be stopped.
15-9 Reserved 0 Reads return 0. Writes have no effect.
8 TEST Test. When this bit is set, the parity bits are mapped into the peripheral RAM frame to make them
accessible by the CPU.
0 Parity bits are not memory-mapped.
1 Parity bits are memory-mapped.
7-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 PARITY_ENA Enable/Disable Parity Checking. This bit field enables or disables the parity check on read
operations and the parity calculation on write operations. If parity checking is enabled and a parity
error is detected, then the PEFT flag is set, PAOFF is captured if it is not currently frozen and an
interrupt is generated if it is enabled.
5h Parity check is disabled.
All
Others
Parity check is enabled.
Note: It is recommended to write Ah to enable error detection, to guard against single bit changes
from flipping PARITY_ENA to a disable state.
